Specification:
Unscreened Category 6A Permanent Link
and Channel performance
ANSI/TIA/EIA-568-B.2-10
Electrical:
Current Rating: 1.5 Amps
Insulation Resistance: 500 Mohms Minimum
Contact Resistance: 20 mohms Maximum
DC Resistance: 0.1 ohms Maximum
Mechanical:
Plug Insertion Life: 750 Cycles Minimum
Plug & Jack Contact Force: 100 Grams Minimum
Using FCC-Approved Plug
Plug Retention Force: 30 lbs Minimum
Temperature: -40ºF to 150ºF (-40ºC to 68ºC)
Physicals:
Housing: High Impact Flame Retardant Plastic, UL 94V-0 Rated
Springshielded: 0.25 Thinkness SUS301
PCB: FR4, 1.6mm Thickness
Jack Wiring: 0.42mm Thickness Phosphor Bronze, Gold Over Nickel Plating
Connector: Insulation Displacement Connector
(IDC) Accept #23~26 AWG Solid Wire
Unscreened Category 6A Permanent Link
and Channel performance
ANSI/TIA/EIA-568-B.2-10
Electrical:
Current Rating: 1.5 Amps
Insulation Resistance: 500 Mohms Minimum
Contact Resistance: 20 mohms Maximum
DC Resistance: 0.1 ohms Maximum
Mechanical:
Plug Insertion Life: 750 Cycles Minimum
Plug & Jack Contact Force: 100 Grams Minimum
Using FCC-Approved Plug
Plug Retention Force: 30 lbs Minimum
Temperature: -40ºF to 150ºF (-40ºC to 68ºC)
Physicals:
Housing: High Impact Flame Retardant Plastic, UL 94V-0 Rated
Springshielded: 0.25 Thinkness SUS301
PCB: FR4, 1.6mm Thickness
Jack Wiring: 0.42mm Thickness Phosphor Bronze, Gold Over Nickel Plating
Connector: Insulation Displacement Connector
(IDC) Accept #23~26 AWG Solid Wire
檔案下載：TA806AUX
