Electrical:
Current rating: 1.5Amps
Insulation resistance: 500MΩ mina/500V.
Contact resistance: 20mΩ max.
Dielectric withstanding: Voltage 1000VAC RMS 60Hz
Mechanical:
Extension: 7.7Kgf(17lbf) between the socket and plug
Reliability: 500 Mating cycles.
Physicals:
Housing: PBT 94V0+15% fiber color blue (Pantone blue 285C).
Contacts: Ø0.46mm phosphor bronze gold plating
Short plate: Phosphor bronze gold plating
Current rating: 1.5Amps
Insulation resistance: 500MΩ mina/500V.
Contact resistance: 20mΩ max.
Dielectric withstanding: Voltage 1000VAC RMS 60Hz
Mechanical:
Extension: 7.7Kgf(17lbf) between the socket and plug
Reliability: 500 Mating cycles.
Physicals:
Housing: PBT 94V0+15% fiber color blue (Pantone blue 285C).
Contacts: Ø0.46mm phosphor bronze gold plating
Short plate: Phosphor bronze gold plating
